Honeywell Voyager 1202G wireless laser barcode scanner

Overview

The Honeywell Voyager™ 1202G wireless laser barcode scanners are built on the world’s best-selling single-line laser scanner platform. They aggressively scan virtually all linear barcodes. And they do an exceptional job of reading poor quality and even damaged barcodes. Part of our Honeywell collection of scanners.

Download Product Specification

Register to get started

Apply for a ForPOS account to view pricing, receive exclusive discounts and some other incentive etc etc.

My account

Key Features

  • Single Line Scan
  • USB, RS232, RS485, KBW
  • Reads standard 1D and GS1 Databar symbololgies
  • Excellent Poor Quality Code Reading
  • Long Battery Life and Tool-Free Battery Removal
  • Automatic Interface Configuration
  • Bluetooth® Wireless Technolog

The Voyager 1202g wireless barcode scanners give you able-bodied performance and flexibility for a wide variety of hands-free and handheld scanning applications. Voyager scanners deliver aggressive scan performance on virtually all linear barcodes.

  • Decode poorly printed, smudged, faded and other difficult-to-read barcodes with ease.
  • Scan high-density barcodes, too, with resolution down to 3.5 mil. In most cases, that eliminates the need to purchase specialty scanners.

And take advantage of the Voyager scanner’s class-leading, hands-free presentation scanning. It maximizes throughput with updated object detection and automatic in-stand detection and configuration.

Honeywell designed these Voyager scanners to decrease your downtime and service costs too.

  • Single shock-mounted PCB delivers greater impact resistance.
  • Recessed button is protected by an integrated rubber co-mold that minimizes the impact of accidental drops.
  • Designed with a protected, scratch-resistant glass window and an IP42-rating.

The Voyager 1202g wireless model incorporates a Bluetooth® Class 2 radio. You’ll have unrestricted movement up to 10 m (33 ft) from the base, and up to 30 m (100 ft) with a clear line-of-sight between scanner and base.

And if you ever misplace a scanner, the Voyager’s paging system uses visual and auditory signals to help you find the missing device quickly.

Specification
Radio/Range 2.4 to 2.5 GHz (ISM Band) Adaptive Frequency Hopping Bluetooth v2.1; Class 2: 10m (33’) line of sight
Data Rate (Transmission Rate) Up to 3 Mbps
Battery 1800 mAh Lithium ion minimum
Number of Scans Up to 45,000 scans per charge
Expected Hours of Operation 12 hours
Expected Charge Time 4 hours
Dimensions (LxWxH) - Scanner: Voyager 1202g 5°C to 40°C (41°F to 104°F)
Dimensions (LxWxH) - Charge and Communication Base: CCB00-010BT 200 mm x 67 mm x 97 mm (7.9˝ x 2.6˝ x 3.8˝)
Weight - Scanner: Voyager 1202g 180 g (6.3 oz) (includes battery)
Weight - Charge and Communication Base: CCB00-010BT 185 g (6.5 oz)
Operating Power (Charging) - Scanner: Voyager 1202g N/A
Operating Power (Charging) - Charge and Communication Base: CCB00-010BT 5 W (1 A @ 5 V with power supply); 2.5W (0.5 A @ 5 V with USB)
Non-Charging Power - Scanner: Voyager 1202g N/A
Non-Charging Power - Charge and Communication Base: CCB00-010BT 0.625 W (0.125 A @ 5 V)
Host System Interfaces - Scanner: Voyager 1202g N/A
Host System Interfaces - Charge and Communication Base: CCB00-010BT USB, Keyboard Wedge, RS232, IBM 46xx (RS485)
Operating Temperature - Scanner: Voyager 1202g 5°C to 40°C (41°F to 104°F)
Operating Temperature - Charge and Communication Base: CCB00-010BT Charging: 5°C to 40°C (41°F to 104°F); Non-Charging: 0°C to 50°C (32°F to 122°F)
Storage Temperature with Battery - Scanner: Voyager 1202g -5°C to 35°C (23°F to 95°F)
Storage Temperature with Battery - Charge and Communication Base: CCB00-010BT -5°C to 35°C (23°F to 95°F)
Humidity - Scanner: Voyager 1202g 0 to 95% relative humidity, non-condensing
Humidity - Charge and Communication Base: CCB00-010BT 0 to 95% relative humidity, non-condensing
Drop - Scanner: Voyager 1202g Designed to withstand 30 1.5 m (5´) drops to concrete
Drop - Charge and Communication Base: CCB00-010BT Designed to withstand 30 1 m (3.3´) drops to concrete
Environmental Sealing - Scanner: Voyager 1202g IP42
Environmental Sealing - Charge and Communication Base: CCB00-010BT IP42
Light Levels - Scanner: Voyager 1202g 0 to 70,000 lux (6,500 foot-candles)
Light Levels - Charge and Communication Base: CCB00-010BT N/A
Scan Pattern Single scan line
Scan Speed (laser only) 100 scan lines per second
Scan Angle Horizontal: 30°
Print Contrast 10% minimum reflectance difference
Pitch, Skew 60°, 60°
Decode Capabilities Reads standard 1D and GS1 DataBar symbologies. (Note: Decode capabilities dependent on kit configuration)
Warranty 3 year factory warranty (Note: battery warranty is 1 year)
