Posiflex KS-7410 10” PCAP touch screen POS Terminal

Overview

The sleek, bezel-free Posiflex KS-7410 POS terminal not only brings a modern aesthetic to the counter. The KS-7410 POS terminal also has a compact footprint also creates the extra counter space which is exactly what small to medium-sized retail companies desire. Part of the Posiflex KS Series. Drivers and utilities can be found here.

Download Product Specification

Register to get started

Apply for a ForPOS account to view pricing, receive exclusive discounts and some other incentive etc etc.

My account

Key Features

  • 9.7” TFT LCD PCAP touch screen
  • Intel Bay Trail J1900 Quad Core
  • Up to 8Gb RAM
  • 64GB SSD as standard
  • small form factor

Small but Delicate
Despite its small form factor, the KS-7410 comes with 10” PCAP touch screen that is easy on the eyes and even easier to clean. With the built-in MSR, the Posiflex KS-7410 greatly enhances the convenience of cashier’s operation.

Performance
Powered by Intel J1900 CPU running at 2.42GHz, which is more than enough to handle any daily operation.

Fanless Design
Solve the fan maintenance issue and provide silent mode operation, which is ideally suited for retail stores or fine dining environments.

Expandable and Flexible
Connect to a wide range of accessories for greater productivity and flexibility to fit in your store environment.

Complete your POS bundle by adding a cash drawer and printer to your order.
The ForPOS range of cash drawers will meet any retail and hospitality need. Heavy duty for harsh environments or flip top for a compact space saver the ForPOS range of cash drawers offer reliability and high quality.
ForPOS also offer a wide range of receipt, label and mobile printers.  Compatible with all major operating systems and with a range interface options and accessories.

System Configuration
Processor Intel Bay Trail J1900 Quad Core CPU, up to 2.42 GHz, 2M Cache
System Memory DDR3L SO-DIMM slot x 1, max. 8GB
Storage Device SATA Storage x 1
Power Supply 12V/60W
OS Support Windows 7/POSReady 7/Windows Embedded 8.1 Industry/Windows 10 IoT/Linux per request
Display & Touch
LCD 9.7” TFT LCD
Resolution 1024 x 768
Touch True-flat PCAP touch with multi-touch support (IP65 on front panel)
I/O Expansion
Serial Port 3, DB9 x 1 + RJ50 x 2, 5V/12V support on all COM ports
Standard USB Port USB 2.0 x 6
Parallel Port 1, via optional conversion cable through service window
LAN Port 10/100/1000 Mb x 1
Display Port VGA x 1, 12V support for Posiflex monitors
CR Port 1, control 2 CR via optional Y-cable
PS/2 Port 1, via optional conversion cable through service window
Audio Internal 2W speaker x 1 + line-out
Expansion Slot M.2 slot x 1
Physical Dimension
Dimension (W x D x H in mm) 260 x 205 x 266
Weight (N. W. in kg) 3
Environmental
Operating Condition 0°C – 40°C, 20%RH – 90%RH (Equipped with HDD); 0°C – 50°C, 20%RH – 90%RH (Equipped with SSD)
Storage Condition -20°C – 70°C, 10%RH – 90%RH
Built-in Options
WiFi
MSR 3 track module (HID/VCOM Selectable)
